A four-storey mixed-use project on Rue Saint-Georges hit a planning delay last fall because the municipal review flagged uncertain soil amplification across the glacial till and sensitive clay pockets that underlie much of Saint-Jerome. The city sits on the edge of the Laurentian foothills at 45.778° N, where the Rivière du Nord carved a valley through Champlain Sea deposits — a setting that creates abrupt lateral changes in shear-wave velocity over just a few hundred metres. Standard NBCC site classification alone wouldn't resolve the variation, so we ran a multi-method campaign combining MASW profiles with microtremor recordings to build a site-specific ground-motion map that satisfied both the municipality and the structural engineer. Seismic microzonation in Saint-Jerome isn't just an academic exercise; it directly determines whether a deep foundation, ground improvement, or a revised structural period is needed before the first footing is poured.
A one-letter site class isn't enough when the till thickness doubles across the property — that's when microzonation pays for itself in foundation savings.
Process and scope
Site-specific factors
In Saint-Jerome, we repeatedly encounter a specific problem: the surficial sand and gravel cap is thin — maybe 1.5 to 3 metres — but it masks a thick sequence of Champlain Sea silty clay that grades from stiff near the top to soft and normally consolidated at depth. A builder who relies only on a borehole log without a shear-wave profile will likely classify the site as Class C or D by the 30-metre average, yet the fundamental period may exceed 0.5 seconds, placing it firmly in a higher spectral acceleration band that governs the base shear calculation. We've seen cases along Boulevard Antoine-Labelle where the amplification factor at one-second period jumped by 40 percent between two boreholes spaced 80 metres apart because the clay pinched out against a buried bedrock ridge. Missing that means an under-designed lateral system: cracked partition walls, jammed doors, and a structural retrofit bill that dwarfs the cost of the original microzonation campaign.
Watch the video
Reference standards
NBCC 2020 – Division B, Part 4, Seismic Hazard and Site Classification, CSA A23.3-19 – Design of Concrete Structures, seismic provisions, ASTM D7400-19 – Standard Test Methods for Downhole Seismic Testing (referenced for Vs profiling), Eurocode 8 – EN 1998-1 reference for ambient vibration HVSR interpretation guidelines, NBC 2015 – complementary provisions for existing building seismic evaluation
Other technical services
Site-specific ground response analysis
One-dimensional equivalent-linear analysis using DEEPSOIL or SHAKE2000, calibrated with the Vs profile and modulus reduction curves matched to the Saint-Jerome Champlain clay. We output surface acceleration time histories and response spectra at the foundation level for NBCC compliance.
Liquefaction susceptibility mapping
Grid-based assessment correlating SPT blow counts from our SPT drilling program with the mapped peak ground acceleration and the fine-content thresholds for the Saint-Jerome silty sand lenses. We delineate zones requiring densification or stone column treatment before construction.
Typical parameters
Frequently asked questions
How much does a seismic microzonation study cost for a typical Saint-Jerome lot?
For a standard commercial or multi-residential lot in Saint-Jerome, a microzonation campaign that includes 8 to 12 MASW lines plus an equivalent number of HVSR stations runs between CA$6,280 and CA$26,190. The spread depends on grid density, access constraints, and whether we need to integrate existing borehole logs or drill new SPT holes for liquefaction assessment.
Does the City of Saint-Jerome require microzonation for a building permit?
The municipality doesn't always mandate a full microzonation study by name, but when the geotechnical report flags a Site Class E or a significant lateral variability in the soil profile, the building official will often request a site-specific hazard assessment under NBCC 2020 Clause 4.1.8.4. We've supported several permit applications along the Rivière du Nord corridor where the microzonation report was the key document that unlocked approval.
What's the difference between a standard site classification and a microzonation?
A standard NBCC site classification gives you a single letter — A through E — based on the average shear-wave velocity in the top 30 metres. A microzonation maps how that letter changes across your site, but also delivers the fundamental period, the amplification spectrum, and the spatial distribution of spectral acceleration at key periods. For a Saint-Jerome project where the clay thickness varies sharply, the microzonation identifies the worst-case corner of the building footprint so the structural design isn't based on an optimistic average.
