Specifying a granular base thickness based on generic Ontario standards in Saint-Jerome is the fastest way to see alligator cracking after two winter cycles. The Rivière du Nord valley deposits a mix of Champlain Sea silty clays and glaciolacustrine sediments that lose stiffness dramatically during the March–April thaw. A pavement structure that works in Laval fails here because the frost penetration depth routinely exceeds 2.1 meters, and the native subgrade often classifies as CL-ML with a resilient modulus below 40 MPa when saturated. We combine CBR laboratory testing with layered elastic analysis using actual axle load spectra from Route 117 and Rue Bélanger traffic counts, then calibrate the asphalt and base thickness to survive 25-year design ESALs under Saint-Jerome’s freeze-thaw regime.
A subgrade resilient modulus drop from 60 MPa to 18 MPa during spring thaw can reduce pavement fatigue life by 80%—this is the reality in Saint-Jerome’s Champlain Sea clays.
Process and scope
Site-specific factors
The Benkelman beam and falling weight deflectometer we operate on Saint-Jerome streets measure a pavement’s actual deflection basin under a 40 kN impulse load, and the numbers often surprise engineers who trusted office-based estimates. When the back-calculated subgrade modulus comes back at 22 MPa in April versus the 55 MPa assumed during design, the entire fatigue life equation shifts downward. That gap—between the as-designed structural number and the as-built reality—is where premature rutting and bottom-up fatigue cracking originate. We run FWD testing in early spring specifically to capture the worst-case saturated condition, because a pavement section that survives the April weak period in Saint-Jerome will perform through the rest of the year without distress.
Watch the video
Reference standards
AASHTO Guide for Design of Pavement Structures (1993, with 1998 supplement), Asphalt Institute Manual Series No. 2 (MS-2), 7th or 8th Edition, CSA A23.1/A23.2 – Concrete materials and methods (subbase/base if stabilized), BNQ 2560-114 – Granular materials (Quebec standard for base/subbase), MTQ Standard 4202 – Hot mix asphalt formulation (Quebec transport ministry), ASTM D1883 / AASHTO T 193 – California Bearing Ratio (CBR) test
Other technical services
Subgrade Characterization and CBR Testing
We sample the native Champlain Sea silty clay and glacial till at 0.5 m depth intervals down to 2.5 m, running laboratory CBR (ASTM D1883), Proctor compaction, and resilient modulus triaxial tests to build a reliable subgrade stiffness profile for the AASHTO structural number calculation.
Traffic Analysis and Structural Thickness Design
Using actual weigh-in-motion data or axle load surveys from Saint-Jerome corridors, we convert mixed traffic to 18-kip ESALs over the design life, then compute asphalt, base, and subbase thicknesses per the Asphalt Institute MS-2 layered elastic method with local climate adjustments.
Frost Protection and Drainage Design
We calculate the required frost protection layer thickness to prevent ice lens formation in the subgrade, specify granular base gradation that resists capillary rise, and detail geotextile separation and edge drain geometry to keep the pavement structure drained through Saint-Jerome’s spring thaw period.
Typical parameters
Frequently asked questions
What is the typical cost range for a flexible pavement design package in Saint-Jerome?
For a municipal or commercial project in Saint-Jerome, the design package—including subgrade investigation, laboratory CBR and triaxial testing, traffic analysis, and the final cross-section with structural number calculations—ranges from CA$2,180 to CA$7,290 depending on project length and traffic complexity. A short access road with low truck volume sits at the lower end; a multi-lane arterial with weigh-in-motion data and FWD verification reaches the upper range.
How does Saint-Jerome's climate affect flexible pavement design compared to Montreal?
Saint-Jerome lies further north and at slightly higher elevation than Montreal, resulting in deeper frost penetration—typically 2.0 to 2.3 meters versus 1.6 meters in Montreal—and a longer spring thaw recovery period. This demands a thicker granular base for frost protection and a softer asphalt binder grade (PG 58-34) to resist thermal cracking during January cold snaps that can drop below -30°C in the Laurentian valley.
What AASHTO structural number (SN) is typical for arterial roads in Saint-Jerome?
For a collector or minor arterial in Saint-Jerome carrying 2–5 million ESALs over 20 years, the required structural number typically falls between 4.5 and 6.0, depending on the subgrade resilient modulus and drainage conditions. Roads built on the silty clay deposits near the Rivière du Nord floodplain often require an SN above 5.5, achieved through a combination of 150–180 mm of hot mix asphalt and 450–600 mm of granular base.
How do you verify that the constructed pavement meets the design assumptions?
We perform falling weight deflectometer (FWD) testing on the finished subgrade and on each compacted granular layer to back-calculate the in-situ modulus, comparing it against the design values. Asphalt cores are tested for density (ASTM D2726) and thickness, and the binder content and gradation are verified through solvent extraction. Any deviation from the design structural number triggers a revised fatigue and rutting analysis before the project is accepted.
